POCT Analyzer System
Portable Point-Of-Care Testing Platform——Test 3+
  • Practical & Portable
  • No Need Cold-chain Transport
  • Laboratory-based Accuracy
BUY NOW
POCT Analyzer System Specs

TEST ITEM
CRP+ Hs CRP | HbA1C | MAU


TEST

Method

Immunochromatographic Assay

Full name

One step C-Reactive Protein

Hemoglobin A1c

Human Urine Microalbumin

Test name

hsCRP+ CRP

 HbA1C

 MAU

Specimen type

Cb/Wb/P/S

Cb/Wb

U

Test volume

Whole blood: 8μl
Serum / Plasma: 4μl

Whole blood: 4μl

50ul

Test time

3min

5min

3min

Test range

0.5-200mg/l

4%-15%

5-300mg/l

Linear correlation coefficient r

≧0.990

≧0.990

≧0.990

Test accuracy

≤15%

≤8%

≤15%

Storage temperature

4-30℃

4-30℃

4-30℃

Operation temperature

25±3℃

25±3℃

25±3℃

Shelf life (Unopened)

24m

24m

24m

Shelf life (Opened)

1h

1h

1h

Package

25 test/kit

25 test/kit

25 test/kit


ANALYZER

Point-of-care testing analyzer system

Battery

Battery(AA x 4) & AC/DC adapter

Dimensions

105 x 135 x 100 mm

Weight

600g

Display

LCD screen

Memory

1,000 measurement of result

Storage temperature

-10℃ ~ 50℃

Relative humidity

10% ~ 90%

Location

Location Dry, clean, horizontal surface. Avoid direct sunlight.

Connectivity

Indirect LIS/HIS

Thermal printer (Optional)

Yes

Barcode reader (Optional)

Yes
